Productcategorie: JIC hydraulische fittingadapters voor buisaansluiting van vloeistofvermogen
Productstandaard: ISO 8434-2, SAE J514.
Materiaal: koolstofstaal, roestvrij staal of koperlegering.
JIC buisuiteinde naar andere eindverbinding als volgt: BSP Captive seal E, G, H types, fittingen uit de ISO 6149-serie, JIS B2351 fittingen, ISO 11926 en SAE J1926 ORB-fittingen, DIN 3852 en ISO 1179 fittingen, ISO 9974 fittingen etc.
1JT4-SP 45 ° ELLEBOOG JIC MANNETJE 74 ° CONE / BSPT MANNETJE Maattabel als volgt:
PA RT NEE . | T HR EA D | DIMENSIO NS | |||
E | F | EEN | B | S 1 | |
1 J T 4 - 04 - 02 S P | 7/16 " X 20 | R1 / 8 " X 28 | 21.5 | 17 | 11 |
1 J T 4 - 04 S P | 7/16 " X 20 | R1 / 4 " X 19 | 22.3 | 21 | 14 |
1 J T 4 - 04 - 06 S P | 7/16 " X 20 | R3 / 8 " X 19 | 22.5 | 23 | 16 |
1 J T 4 - 04 - 08 S P | 7/16 " X 20 | R1 / 2 " X 14 | 24.5 | 29.5 | 22 |
1 J T 4 - 05 - 02 S P | 1/2 " X 20 | R1 / 8 " X 28 | 21.5 | 17.5 | 14 |
1 J T 4 - 05 - 04 S P | 1/2 " X 20 | R1 / 4 " X 19 | 22.3 | 21 | 14 |
1 J T 4 - 05 - 06 S P | 1/2 " X 20 | R3 / 8 " X 19 | 22.8 | 23 | 16 |
1 J T 4 - 06 - 02 S P | 9/16 " X 18 | R1 / 8 " X 28 | 22.8 | 18 | 14 |
1 J T 4 - 06 - 04 S P | 9/16 " X 18 | R1 / 4 " X 19 | 22.8 | 21 | 14 |
1 J T 4 - 06 S P | 9/16 " X 18 | R3 / 8 " X 19 | 23 | 23 | 16 |
1 J T 4 - 06 - 08 S P | 9/16 " X 18 | R1 / 2 " X 14 | 25 | 29.5 | 22 |
1 J T 4 - 08 - 04 S P | 3/4 " X 16 | R1 / 4 " X 19 | 26.8 | 22 | 19 |
1 J T 4 - 08 - 06 S P | 3/4 " X 16 | R3 / 8 " X 19 | 26.8 | 24 | 19 |
1 J T 4 - 08 S P | 3/4 " X 16 | R1 / 2 " X 14 | 28 | 29.5 | 22 |
1 J T 4 - 08 - 12 S P | 3/4 " X 16 | R3 / 4 " X 14 | 29 | 30.5 | 27 |
1 J T 4 - 10 - 06 S P | 7/8 " X 14 | R3 / 8 " X 19 | 31 | 25 | 22 |
1 J T 4 - 10 - 08 S P | 7/8 " X 14 | R1 / 2 " X 14 | 31 | 29.5 | 22 |
1 J T 4 - 10 - 12 S P | 7/8 " X 14 | R3 / 4 " X 14 | 33 | 31.5 | 27 |
1 J T 4 - 12 - 08 S P | 1.1 / 16 " X 12 | R1 / 2 " X 14 | 35.5 | 30 | 27 |
1 J T 4 - 12 S P | 1.1 / 16 " X 12 | R3 / 4 " X 14 | 35.5 | 30.5 | 27 |
1 J T 4 - 12 - 16 S P | 1.1 / 16 " X 12 | R1 " X 11 | 37.5 | 38 | 33 |
1 J T 4 - 16 - 12 S P | 1,5 / 16 " X 12 | R3 / 4 " X 14 | 38.5 | 32.5 | 33 |
1 J T 4 - 16 S P | 1,5 / 16 " X 12 | R1 " X 11 | 38.5 | 38 | 33 |
1 J T 4 - 16 - 20 S P | 1,5 / 16 " X 12 | R1.1 / 4 " X 11 | 42 | 43 | 41 |
1 J T 4 - 20 - 16 S P | 1,5 / 8 " X 12 | R1 " X 11 | 43 | 42 | 41 |
1 J T 4 - 20 S P | 1,5 / 8 " X 12 | R1.1 / 4 " X 11 | 43 | 43 | 41 |
1 J T 4 - 20 - 24 S P | 1,5 / 8 " X 12 | R1.1 / 2 " X 11 | 46 | 47.5 | 48 |
1 J T 4 - 24 - 20 S P | 1.7 / 8 " X 12 | R1.1 / 4 " X 11 | 49 | 45.5 | 48 |
1 J T 4 - 24 S P | 1.7 / 8 " X 12 | R1.1 / 2 " X 11 | 49 | 47.5 | 48 |
1 J T 4 - 32 S P | 2.1 / 2 " X 12 | R2 " X 11 | 58 | 50 | 63 |
D NB 20 0 NB 50 0 NB 20 0 NB 30 0 Nee Nee een d slee v e shoul d b e o r de r d d sepa r a t el y . T h e nu t NB 20 0 an d slee v e NB 50 0 i s sui t abl e voor mij tr i c t ube , t h e nu t NB 20 0 an d slee v e NB 30 0 i s sui t abl e voor inc h t ube . | |||||
