Producttypen: 5FLW-IN hydraulische SAE flens 3000PIS inch buis
Industriestandaarden: SAE J518, ISO 6162
Verbinding E naar F-stijl: SAE Flens 3000PIS / INCH SOCKET-WELD TUBE
Vorm: recht
Werkdruk: SAE-code 61 is 2,5 tot 31,5 Mpa; SAE-code 62 is 40 MPa.
Fittingen materiaal: messing; Koolstofstaal; Roestvrij staal
Toepassing: Landbouwuitrusting, Automotive Process, Chemische overdracht, Bouwuitrusting, Brandstofoverdracht, Hydraulisch, Productieapparatuur, Marine, Materiaalbehandeling, Mobiele uitrusting, Olieveld, Verpakkingen, Transport
5FLW-IN SAE Flens 3000 PSI adapterfittingen Maattabel tabel als volgt
DEEL NR. | O | D | DIMENSIES | |||||
FLENSGROOTTE | O-RING | LAS BUIS OD D | EEN | D1 | D2 | L | ||
5FLW-08IN | 1/2" | O210 | 1/2" | 7 | 30.2 | 23.9 | 26 | |
5FLW-12-08IN | 3/4" | O214 | 1/2" | 7 | 38.1 | 31.7 | 28 | |
5FLW-12in | 3/4" | O214 | 3/4" | 6.73 | 38.1 | 32 | 30 | |
5FLW-16-12IN | 1" | O219 | 3/4" | 8 | 44.4 | 38 | 30 | |
5FLW-16IN | 1" | O219 | 1" | 8 | 44.4 | 38 | 32 | |
5FLW-20-16IN | 1.1 / 4" | O222 | 1" | 8 | 50.8 | 43 | 32 | |
5FLW-20IN | 1.1 / 4" | O222 | 1.1 / 4" | 8.2 | 50.8 | 43.2 | 35 | |
5FLW-24-16IN | 1.1 / 2" | O225 | 1" | 8.2 | 60.3 | 50.3 | 37 | |
5FLW-24-20IN | 1.1 / 2" | O225 | 1.1 / 4" | 8.2 | 60.3 | 50.3 | 37 | |
5FLW-24IN | 1.1 / 2" | O225 | 1.1 / 2" | 8.2 | 60.3 | 50.3 | 40 | |
5FLW-32-20IN | 2" | O228 | 1.1 / 4" | 9.8 | 71.4 | 62.2 | 37 | |
5FLW-32-24IN | 2" | O228 | 1.1 / 2" | 9.8 | 71.4 | 62.2 | 40 | |
5FLW-32in | 2" | O228 | 2" | 9.8 | 71.4 | 62.2 | 40 |
